How to Use a Netgear EX7000 AC1900 WiFi Repeater

Authored by: Support.com Tech Pro Team

1. Introduction

In This Guide

You'll Learn:

• How to use your Netgear Range Extender.

2. How to Set Up Your Netgear EX7000 AC1900 Nighthawk Wi-Fi Range Extender

Show Me How

Clicking this button will open a new guide that will provide you with steps to resolve your issue.

3. How to Proceed?

Please select an option to proceed.

4. How to Update Your Netgear EX7000 AC1900 Nighthawk Wi-Fi Range Extender

Show Me How

Clicking this button will open a new guide that will provide you with steps to resolve your issue.

5. Retrieve Wi-Fi Credentials

Make sure your device is connected to your Range Extender via its Wi-Fi network, or physically using an ethernet cable before continuing.

1. Open your preferred web browser.


1. In the address bar at the top, enter www.mywifiext.net and press Enter or Return.


1. Enter the Email Address and password you set for your range extender, and select Log In.


1. Select Status on the left.


1. On the right, scroll down to the Access Point Wireless Settings (2.4GHz) and Access Point Wireless Settings (5GHz) sections. The Network Name, also called the SSID, is listed, and the password is listed just below.


6. Connect to Network (Android)

Depending on your exact device (Smartphone or Tablet), and which generation you have, the menu theme and options might look slightly different on your screen. However, the steps should be similar across all Android devices and generations.

1. Open Settings.


1. Select Wi-Fi.


1. Select your extended network from the list.


1.

2. If you're asked for a password, it's the one you just setup on your range extender.

7. Connect to Network (iOS)

Depending on your exact device (Smartphone or Tablet), and which generation you have, the menu theme and options might look slightly different on your screen. However, the steps should be similar across all Apple iOS devices and generations.

1. Open Settings.


1. Select Wi-Fi.


1. Select the extended network you just setup from the list.


1.

2. If you're asked for a password, it's the one you just setup on your range extender.

8. Connect to Network (Windows 10)

Windows 10 may show slightly different options, but the steps should be similar across all versions of Windows 10.

1. Select the Network icon in the bottom right.


1. Select the the network name you setup during the extender setup.


1. Select Connect.


If you're asked for a password, it's the one you just setup on your range extender.

9. Connect to Network (macOS)

macOS may show slightly different options, but the steps should be similar across all versions and themes on macOS.

1. Select Wi-Fi from the menu bar, then select the extended network you just setup.


If you're asked for a password, it's the one you just setup on your range extender.

10. Status Indicators

There are a series of status indicators on the front of your range extender.

Netgear Light

Light Off

No power going to Range Extender.

Light On

The Range Extender is getting power.

Connection Lights

5 GHz Green

The range extender has an optimal 5 GHz connection to your router..

5 GHz Amber

The range extender has a good 5 GHz connection to your router.

5 GHz Red

The range extender has a weak 5 GHz connection to your router. It should be placed closer to your router.

5 GHz Off

The range extender does not have a 5 GHz connection to your router.

2.4 GHz Green

The range extender has an optimal 2.4 GHz connection to your router..

2.4 GHz Amber

The range extender has a good 2.4 GHz connection to your router..

2.4 GHz Red

The range extender has a weak 2.4 GHz connection to your router. It should be placed closer to your router.

2.4 GHz Off

The range extender does not have a 2.4 GHz connection to your router.

Link Green

The range extender is connected to a computer or a Wi-Fi device..

Link Amber

The range extender is starting or applying changes to the Wi-Fi settings. This should turn green in one minute..

Link Off

The extender is not connected to a computer or a Wi-Fi device.

Ethernet Port Indicators

Each of the 5 Ethernet ports has its own indicator lights.

On

When the light is green, there's a device connected to the Ethernet port.

Off

When off, there's no Ethernet device connected, the device is turned off, or isn't talking to the Range Extender.

USB Indicator

On

A USB device is connected and detected by the Range Extender.

Off

No USB device is connected or detected.

11. Check Network Status

You can check the status of your range extender in two ways:

• On the device itself,
• On a computer.

The type and amount of network related information that you get depends on which method you use.

On Your Range Extender

1. Locate the network status indicators near the front of the range extender.


1.


2. Check the Wi-Fi and Link indicators on the front of the range extender:

3. 5 GHz Green

1. The range extender has an optimal 5 GHz connection to your router.
2. 5 GHz Amber

1. The range extender has a good 5 GHz connection to your router.
2. 5 GHz Red

1. The range extender has a weak 5 GHz connection to your router. It should be placed closer to your router.
2. 5 GHz Off

1. The range extender does not have a 5 GHz connection to your router.
2. 2.4 GHz Green

1. The range extender has an optimal 2.4 GHz connection to your router.
2. 2.4 GHz Amber

1. The range extender has a good 2.4 GHz connection to your router.
2. 2.4 GHz Red

1. The range extender has a weak 2.4 GHz connection to your router. It should be placed closer to your router.
2. 2.4 GHz Off

1. The range extender does not have a 2.4 GHz connection to your router.
2. Link Green

1. The range extender is connected to a computer or a Wi-Fi device.
2. Link Amber

1. The range extender is starting or applying changes to the Wi-Fi settings. This should turn green in one minute.
2. Link Off

1. The extender is not connected to a computer or a Wi-Fi device.

On Your Computer

1. Launch the browser that you use to go online.


1. Navigate to the following address: mywifiext.net


1. Enter the password when requested.


1. The Network Map tab will display the range extender's connection to the router, its operation mode and connection to your devices.


12. Location

Finding the most optimal location for your Range Extender in your home is important for both maximizing your signal range and wireless coverage. Your Range Extender has a spot finder during the setup process to help you locate the best location for your device.

You can move your Range Extender from outlet to outlet using the spot finder as a guide for selecting locations that will provide the best wireless performance in your home.

You can also look at the light on the front of the range extender to get a quick idea if it is currently positioned well:

5 GHz Green

The range extender has an optimal 5 GHz connection to your router.

5 GHz Amber

The range extender has a good 5 GHz connection to your router.

5 GHz Red

The range extender has a weak 5 GHz connection to your router. It should be placed closer to your router.

5 GHz Off

The range extender does not have a 5 GHz connection to your router.

2.4 GHz Green

The range extender has an optimal 2.4 GHz connection to your router..

2.4 GHz Amber

The range extender has a good 2.4 GHz connection to your router.

2.4 GHz Red

The range extender has a weak 2.4 GHz connection to your router. It should be placed closer to your router.

2.4 GHz Off

The range extender does not have a 2.4 GHz connection to your router.

In general, you want your Range Extender at least six feet away from your router. At most, you want it half-way between where your router is, and where you want the signal to reach. Finding and testing multiple locations may be necessary if wireless interference is a factor within your home.
